Hospital Elevator
Product Description(Click on the download specific document)
Minastar fuji hospital elevator series, the size of the capsules and the structure is convenient for passengers, meet the needs of hospital various special use, mainly is suitable for the hospitals, nursing homes and other buildings.
Product Specification
| Model | Load Kg |
Speed m/s |
Pers | Car Size (mm) CW×CD×HK |
Opening Size(mm) PL×LH |
Shaft Size(mm) SW×SD |
Machine Room Size(mm) W×D |
Overhead Hight H2 mm |
Pit Depth H1 mm |
Travelling Height H mm |
| MST-HS-1000/1.0 | 1000 | 1 | 13 | 1100×2100×2400 | 900×2100 | 2100×2500 | 2100×2500 | 4300 | 1500 | 50 |
| MST-HS-1000/1.5 | 1000 | 1.5 | 13 | 1100×2100×2400 | 900×2100 | 2100×2500 | 2100×2500 | 4400 | 1500 | 75 |
| MST-HS-1000/1.75 | 1000 | 1.75 | 13 | 1100×2100×2400 | 900×2100 | 2100×2500 | 2100×2500 | 4400 | 1500 | 85 |
| MST-HS-1600/1.0 | 1600 | 1 | 21 | 1400×2400×2400 | 1100×2100 | 2300×2850 | 2300×2850 | 4300 | 1500 | 50 |
| MST-HS-1600/1.5 | 1600 | 1.5 | 21 | 1400×2400×2400 | 1100×2100 | 2300×2850 | 2300×2850 | 4500 | 1500 | 75 |
| MST-HS-1600/1.75 | 1600 | 1.75 | 21 | 1400×2400×2400 | 1100×2100 | 2300×2850 | 2300×2850 | 4500 | 1500 | 85 |
| MST-HS-2000/1.0 | 2000 | 1 | 26 | 1600×2600×2400 | 1200×2100 | 2500×3050 | 2500×3050 | 4300 | 1500 | 50 |
?
